Description

Insulation resistance measurement up to 15T Ohm in Accordance with IEC 61557-2

Test Voltages 50V…1000 V at 10 V and 1000V…5000 V at 25 V resolution.

Continuous indication of measured insulation resistance or leakage current.

• Automatic discharge of measured object capacitance voltage after the end of insulation resistance measurement.
• Acoustic signaling of 5 seconds intervals to facilitate capturing time characteristics.
• Metered T , T and T test times for measuring one or two absorption coefficients from the range of 1…600 s.
• Adjustable measuring time to 99’59’’.
• Polarization index (PI) and dielectric absorption ratio (DAR) measurement.
• Indication of actual test voltage during measurement.
• 1.2 mA and 3 mA test current.
• Step voltage insulation resistance measurement (SV)
• Dielectric Discharge calculation (DD)
• Protection against measuring live objects.
• Measurements with test leads up to 20 m.
• Digital filters function for measurements in high noise enviroment (10 s, 30 s, 60 s)
• Measurement of leakage current during insulation resistance testing.
• Measurement of capacitance during the measurement of RISO.
• DC and AC voltage measurement in the range of 0…600 V.
• Memory.
• Power supply from main power line or battery packs, low battery warning indicator, built-in fast charger.
• Display backlit.
• The instruments meet the requirements of the EN 61557 standard.
